Minus 150 C Impingement Tunnel Freezer 10kw Quick Freezing Machine 200k

Product Categories
Shenzhen Dejieli Refrigeration Technology Co., Ltd.
Contact Now

Minus 150 C Impingement Tunnel Freezer 10kw Quick Freezing Machine 200k

  • 1
  • 2

Place of Origin : Guangdong, China

Brand Name : DJL

Certification : ISO9001 , CE

Packaging Details : CUSTOMIZE

Supply Ability : 35 SETS PER YEAR

Price : negotiable

Model Number : DJL-QFL-1612E

MOQ : 1 set

Payment Terms : T/T

Delivery Time : 45 work days

Applicable Industries : Food & Beverage Factory, Farms

Voltage : customize

Power : customize

Dimension(L*W*H) : customize

Weight : customize

Mode : OEM

Contact Now

Custom Design Food Quick Fast Freezing Tunnel Machine Ultra Low Temperature Freezer

Liquid nitrogen quick freezing is to use this ultra-low temperature and heat absorption characteristics to directly spray it on the required food. At this time, the temperature difference is as high as 200K. It can carry out strong heat exchange and make the poultry freeze instantaneously, generally in about 20 minutes. The entire freezing process can be completed, which is faster than the ordinary ammonia machine freezing method.
Because the freezing time is short, the ice crystals produced are very small, and the freezing speed is greater than the steam penetration speed inside and outside the cell. Ice crystals are produced inside and outside the cell at the same time, which has no destructive effect on the cell. Therefore, the original color, aroma, and taste of the food can be maintained after thawing. Fresh state.

Equipment material: SUS304 stainless steel
Working temperature: -150℃~room temperature
Temperature control precision: ±2℃
Temperature uniformity: ±5℃
Cooling rate: ≥20℃/min
Heating rate: ≥5℃/min
Distribution specification: 380V/50HZ
Specification
Model
Tunnel length
(mm)
Wire belt width
(mm)
Tunnel height
(mm)
Power
(KW)
freezing capacity
(kg/h)
DJL-QFL-1206
6000
 1200
1750
 10 400-600
DJL-QFL-1209
9000
 1200 1750 12 800-1000
DJL-QFL-1212
 12000 1200 1750 18 1000-1200
DJL-QFL-1609
 9000 1600 1750 15 1000-1200
DJL-QFL-1612 12000
1600
 1750 28 1800-2100
DJL-QFL-1618
 18000 1600 1750 32 2000-2500
DJL-QFL-1815 15000 1800 1750 28 2000-2500
DJL-QFL-1818 18000 1800 1750 32 2200-2800
DJL-QFL-1824
24000
 1800 1750 46 2800-3500

Minus 150 C Impingement Tunnel Freezer 10kw Quick Freezing Machine 200k
Minus 150 C Impingement Tunnel Freezer 10kw Quick Freezing Machine 200k

Our Advantages
1. More than 10 years of professional recognition for ultra-low temperature deep cooling ,own independent intellectual property rights with more than 10 patented technologies.
2. The ability of compound innovation and multi-technology integration makes DJL unique in freezing machine industry.
3. Personalized scheme provides you the best cost performance of product
4. Close cooperative relationships with many universities
5. Three minutes quick-freezing ,the temperature low to minimum -196℃
6. Reasonable &exclusive quick-freezing total solution maximize utilize/save customers cost.
7. Free experiment and verification supporting .
8. Better serving customers by setting up branches and offices in country's areas.
